Morooka Rubber Track Carrier Capacity 2.5T - 5T
| Morooka Model | MST-300VD | MST-300VDR | MST-600VD | MST-700VD | MST-700VDR | MST-800VD |
| Machine Weight | 2,685 kg | 2,710 kg | 4,400 kg | 5,800 kg | 4,930 kg | 7,200 kg |
| Maximum Payload | 2,500 kg | 2,500 kg | 3,800 kg | 4,300 kg | 4,000 kg | 5,000 kg |
| Loading Capacity (Struck/Heaped) | 0.87 m³ / 1.23 m³ | 0.81 m³ / 1.26 m³ | 1.28 m³ / 1.95 m³ | 1.67 m³ / 2.60 m³ | 1.48 m³ / 1.80 m³ | 1.82 m³ / 2.95 m³ |
| Engine | Kubota V2203 | Kubota V2203 | Kubota V3307 | Kubota V3800 | Kubota V3307-CR-T-YDN | CAT C4.4 |
| Tier 4 Interim, EU Stage IIIA | Tier 4 Interim, EU Stage IIIA | Tier 4 Interim, EU Stage IIIA | Tier 4 Interim, EU Stage IIIB | Tier 4 Final / EU Stage V | ||
| Rated Output | 35.4 kW / 2,800 rpm | 35.4 kW / 2,800 rpm | 54.6 kW / 2,200 rpm | 69.2 kW / 2,200 rpm | 52.5 kW / 2,600 rpm | 92.6 kW / 2,200 rpm |
| Battery | 12V, 64Ah | 12V, 64Ah | 12V, 64Ah | 12V, 64Ah × 2 | 12V, 120Ah (5 hour rate) × 2 | 12V, 100Ah × 2 |
| Overall Length | 3,150 mm | 3,490 mm | 3,780 mm | 4,520 mm | 3,900 mm | 4,500 mm |
| Overall Width | 1,745 mm | 1,745 mm | 2,100 mm | 2,200 mm | 2,100 mm | 2,455 mm |
| Overall Height | 2,330 mm | 2,330 mm | 2,330 mm | 2,580 mm | 2,615 mm | 2,710 mm |
| Dump Bed (Length × Width × Height) | 1,675 mm × 1,410 mm × 370 mm | 1,965 mm × 1,465 mm × 310 mm | 2,150 mm × 1,700 mm × 360 mm | 2,500 mm × 1,850 mm × 360 mm | 2,000 mm × 1,900 mm × 370 mm | 2,600 mm × 2,000 mm × 350 mm |
| Dump Angle | 65° | 60° | 60° | 55° | 67° | 48° |
| Ground Clearance | 275 mm | 275 mm | 350 mm | 350 mm | 455 mm | 425 mm |
| Slew Radius | - | - | - | - | 2,310 mm | - |
| Crawler Width | 350 mm | 350 mm | 500 mm | 500 mm | 500 mm | 600 mm |
| Drive System | HST | HST | HST | HST | HST | HST |
| Travel Speed (Lo/Hi) | 6.0 / 9.0 km/h | 6.0 / 9.0 km/h | 7.0 / 10.0 km/h | 7.0 / 10.0 km/h | 7.6 / 10.8 km/h | 6.7 / 9.6 km/h |
| Ground Pressure (Empty) | 29.4 kPa | 29.7 kPa | 24.8 kPa | 24.9 kPa | 25.9 kPa | 24.6 kPa |
| Structure | Canopy, ROPS | Canopy, ROPS | Canopy, ROPS | Canopy, ROPS / FOPS I | Canopy, ROPS / FOPS | Cabin, ROPS / FOPS II |
| Fuel Tank Capacity | 45L | 45L | 75L | 100L | 105 L | 140L |
| Travel Lever Type | Single Lever | Single Lever | 2 levers | 2 levers | Electric Joystick levers | 2 levers |
| Dump Bed Type | Drop Side Rear Door | Scoop End | Drop Side Rear Door | Drop Side Rear Door | Scoop End | Drop Side Rear Door |
